5107 High Temperature Resistance Wire
Description
Name:High Temperature Resistance Wire
Model:AWM5107
Size:26~4AWG
Feature
Ratings Voltage:600V
Rated temperature: -60ºC~+450ºC
Structure
Conductor:Stranded Nickel Copper,Nickel
Insulation:Mica tape , Fiberglass
Braid with High Temperature Finish
Standard:UL758,UL1581
Description
Name:High Temperature Resistance Wire
Model:AWM5107
Size:26~4AWG
Feature
Ratings Voltage:600V
Rated temperature: -60ºC~+450ºC
Structure
Conductor:Stranded Nickel Copper,Nickel
Insulation:Mica tape , Fiberglass
Braid with High Temperature Finish
Standard:UL758,UL1581
| Size AWG | Conductor Structure | Insulation Thickness (mm) | Braid Thickness (mm) | Diameter (mm) |
| 26 | 7/0.16 | ≥0.64 | ≥0.18 | 2.2±0.1 |
| 24 | 7/0.2 | 2.4±0.1 | ||
| 22 | 7/0.254 | 2.5±0.1 | ||
| 20 | 10/0.254 | 2.7±0.1 | ||
| 18 | 16/0.254 | 2.9±0.1 | ||
| 16 | 26/0.254 | 3.2±0.1 | ||
| 14 | 41/0.254 | 3.6±0.1 | ||
| 12 | 65/0.254 | 4.1±0.1 | ||
| 10 | 103/0.254 | ≥0.76 | ≥0.38 | 5.6±0.2 |
| 8 | 163/0.254 | 6.5±0.2 | ||
| 6 | 260/0.254 | 7.6±0.2 | ||
| 4 | 413/0.254 | 8.9±0.2 |
