5107 High Temperature Resistance Wire
Description
Name:High Temperature Resistance Wire
Model:AWM5107
Size:26~4AWG
Feature
Ratings Voltage:600V
Rated temperature: -60ºC~+450ºC
Structure
Conductor:Stranded Nickel Copper,Nickel
Insulation:Mica tape , Fiberglass
Braid with High Temperature Finish
Standard:UL758,UL1581
Specification
Hot Products
Certificates
Company Information
Transport&Shipping
Our Services
1. OEM service available based on official & legal authorization.
2. Strict quality control system.
3. Timely deliverly.
4. Excellent quality with affordable price.
5. Strong technical support.
6. Mobile on 24 hours for any question.
FAQ
1. Why the price is so low?
You are ordering directly from the factory.
2.Where is your factory located? How can I visit there?
Our factory is located in Yangzhou City, Jiangsu Province, China,which is near Shanghai. All our clients, from home or abroad, are warmly welcomed to visit us.
3.Can I get some samples?
Yes, we are honored to offer you samples.
4. Can you make the products with my design?
Yes. customization is welcome .
Description
Name:High Temperature Resistance Wire
Model:AWM5107
Size:26~4AWG
Feature
Ratings Voltage:600V
Rated temperature: -60ºC~+450ºC
Structure
Conductor:Stranded Nickel Copper,Nickel
Insulation:Mica tape , Fiberglass
Braid with High Temperature Finish
Standard:UL758,UL1581
Specification
Size AWG | Conductor Structure | Insulation Thickness (mm) | Braid Thickness (mm) | Diameter (mm) |
24 | 7/0.2 | ≥0.63 | ≥0.18 | 2.3±0.2 |
22 | 7/0.254 | 2.4±0.2 | ||
20 | 10/0.254 | 2.6±0.2 | ||
18 | 16/0.254 | 2.8±0.2 | ||
16 | 26/0.254 | 3.2±0.2 | ||
14 | 41/0.254 | 3.6±0.2 | ||
12 | 65/0.254 | 4.2±0.2 | ||
10 | 103/0.254 | ≥0.76 | ≥0.38 | 5.2±0.2 |
8 | 163/0.254 | 6.6±0.2 |
