UL3321 standard XLPE insulated cable, wire and cable, heat-resistant wire

UL3321 Standard XLPE Insulation Cable, Electric Wire and Cable,Heat Resistant Electric WireRated temperature:150ºCRated voltage:600VReference standard:UL758,UL1581,CSA C22.2Solid or stranded ,tinned or bare copper conductor 30-10AWGXLPE insulation ,comply with ROHS environmental standardPasses UL VW-1 and CSA FT2 flame test
send email to us

Featured Products

UL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric Wire

UL3321 Standard XLPE Insulation Cable, Electric Wire and Cable,Heat Resistant Electric Wire

Rated temperature:150ºC
Rated voltage:600V
Reference standard:UL758,UL1581,CSA C22.2
Solid or stranded ,tinned or bare copper conductor 30-10AWG
XLPE insulation ,comply with ROHS environmental standard
Passes UL VW-1 and CSA FT2 flame test
Uniform insulation thickness to ensure easy stripping and cutting
For motor leads internal wiring of appliance

ConductorFinished productMaximum Resistance at 20ºC
AWGNO.of CondInsulation Thick.Outside Thick.Packing
mmmmmmm/rΩ/mm
307/0.10.79 1.90 610354.33
287/0.1270.79 2.00 610223.75
267/0.160.79 2.05 610139.76
2411/0.160.79 2.20 61088.36
2217/0.160.79 2.40 61060.16
2021/0.1780.79 2.55 61038.58
1834/0.1780.79 2.75 61022.98
1626/0.2540.79 3.10 30515.06
1441/0.2540.79 3.50 3059.65
1265/0.2540.79 3.95 3056.07
1065/0.3200.79 5.00 3053.73

UL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric WireUL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric WireUL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric WireUL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric WireUL3321 Standard XLPE Insulation Cable, Electric Wire and Cable, Heat Resistant Electric Wire
